| 608057B | 608057C | 608057D | 608057E | |
|---|---|---|---|---|
| System specifications | ||||
| Size | A (26.9 mm) | B (33.7 mm) | C (42.4 mm) | D (48.3 mm) |
| Type | Collar plate | Collar plate | Collar plate | Collar plate |
| Color | Silver | Silver | Silver | Silver |
| Specifications tubefittings | ||||
| Size | B | C | D | E |
| Weight (kg) | 0.26 | 0.354 | 0.414 | 0.5528 |
| Diameter (mm) | 26.9 | 33.7 | 42.4 | 48.3 |
| Amount in box | 80 | 60 | 40 | 25 |
| Masterbox specifications | ||||
| Width (cm) | 24 | 24 | 24 | 24 |
| Height (cm) | 22.5 | 22.5 | 22.5 | 22.5 |
| Depth (cm) | 28.5 | 28.5 | 28.5 | 28.5 |
| General additional specifications | ||||
| Measurements screw | 1/4" x 12,5 mm | 1/4" x 12,5 mm | 3/8” x 12,7 mm | 3/8” x 12,7 mm |
| Commodity code | 7308909890 | 7308909890 | 7308909890 | 7308909890 |
| Country of origin | CN | CN | CN | CN |
