| 6080Z09B | 6080Z09C | 6080Z09D | 6080Z09E | |
|---|---|---|---|---|
| System specifications | ||||
| Size | A (26.9 mm) | B (33.7 mm) | C (42.4 mm) | D (48.3 mm) |
| Type | Coupling | Coupling | Coupling | Coupling |
| Color | Black | Black | Black | Black |
| Specifications tubefittings | ||||
| Size | B | C | D | E |
| Weight (kg) | 0.15 | 0.24 | 0.35 | 0.41 |
| Diameter (mm) | 26.9 | 33.7 | 42.4 | 48.3 |
| Tube diameter (") | ¾ | 1 | 1¼ | 1½ |
| Amount in box | 150 | 100 | 70 | 50 |
| Masterbox specifications | ||||
| Width (cm) | 24 | 24 | 24 | 24 |
| Height (cm) | 22.5 | 22.5 | 22.5 | 22.5 |
| Depth (cm) | 28.5 | 28.5 | 28.5 | 28.5 |
| General additional specifications | ||||
| Measurements screw | 1/4" x 16,5 mm | 1/4" x 19 mm | 3/8” x 24 mm | 3/8” x 24 mm |
| Commodity code | 7308909890 | 7308909890 | 7308909890 | 7308909890 |
| Country of origin | CN | CN | CN | CN |
