| 6080X02C | 6080X02D | 6080X02E | |
|---|---|---|---|
| System specifications | |||
| Size | B (33.7 mm) | C (42.4 mm) | D (48.3 mm) |
| Type | Tee | Tee | Tee |
| Color | Black | Black | Black |
| Specifications tubefittings | |||
| Size | C | D | E |
| Weight (kg) | 0.3 | 0.46 | 0.506 |
| Diameter (mm) | 33.7 | 42.4 | 48.3 |
| Tube diameter (") | 1 | 1¼ | 1½ |
| Amount in box | 55 | 30 | 20 |
| Masterbox specifications | |||
| Width (cm) | 24 | 24 | 24 |
| Height (cm) | 22.5 | 22.5 | 22.5 |
| Depth (cm) | 28.5 | 28.5 | 28.5 |
| General additional specifications | |||
| Measurements screw | 1/4" x 12,5 mm | 3/8” x 12,7 mm | 3/8” x 12,7 mm |
| Commodity code | 7308909890 | 7308909890 | 7308909890 |
| Country of origin | CN | CN | CN |
