| 6080X12C | 6080X12D | |
|---|---|---|
| System specifications | ||
| Size | B (33.7 mm) | C (42.4 mm) |
| Type | Flange | Flange |
| Color | Black | Black |
| Specifications tubefittings | ||
| Size | C | D |
| Weight (kg) | 0.75 | 0.98 |
| Tube diameter (") | 1 | 1¼ |
| Amount in box | 20 | 15 |
| Masterbox specifications | ||
| Width (cm) | 24 | 24 |
| Height (cm) | 22.5 | 22.5 |
| Depth (cm) | 28.5 | 28.5 |
| General additional specifications | ||
| Measurements screw | 1/4" x 12,5 mm | 3/8” x 12,7 mm |
